Baumer EIL580 Incremental Encoder
Industrial incremental encoder, Ø58 mm
Ø58 mm incremental encoder with optical sensing, TTL or HTL output, up to 5000 pulses per revolution and protection up to IP67.
- Up to 5000 pulses per revolution
- TTL or HTL output
- Axial, radial or tangential connection
- Protection up to IP67; high shock and vibration resistance
Adding to the list only saves it in your browser. Nothing is sent until you press a send button on the enquiry page. Price and availability are given on quotation.
Specifications
- Size
- Ø58 mm
- Mounting
- Clamping flange
- Output level
- TTL or HTL
- Pulses per revolution
- Up to 5000
- Protection
- Up to IP67
Specifications are given to identify and compare products. Confirm the exact model, ratings and options against the manufacturer’s datasheet, or with us, before ordering.
Choosing the right one
Not sure this is the right sensors and encoder? Read the buying guide for sensors and encoders, then send us the details below so we can confirm a model.
- Sensor type: inductive, photoelectric, fibre, pressure or encoder
- Sensing distance, or pulses per revolution and shaft size for encoders
- Supply voltage and output type (NPN/PNP, NO/NC)
- Housing size or mounting details
- Existing part number if you are replacing a unit
