Autonics BUP and BMS Photoelectric Sensors
Slot-type through-beam and diffuse photoelectric sensors
Compact photoelectric sensors: the BUP-50S is a 50 mm slot-type through-beam sensor and the BMS300-DDT is a 300 mm diffuse-reflective sensor. Both use an infrared LED.
- BUP-50S: through-beam, 50 mm sensing distance, NPN open-collector output
- BMS300-DDT: diffuse reflective, 300 mm sensing distance
- Infrared LED (940 nm)
Adding to the list only saves it in your browser. Nothing is sent until you press a send button on the enquiry page. Price and availability are given on quotation.
Specifications
- Light source
- Infrared LED, 940 nm
- Supply (BUP-50S)
- 12 – 24 V DC ±10%
Specifications are given to identify and compare products. Confirm the exact model, ratings and options against the manufacturer’s datasheet, or with us, before ordering.
Models and ratings
Add a specific model to your enquiry list with its own quantity.
| Model | Type | Sensing distance | Target | Enquiry |
|---|---|---|---|---|
| BUP-50S | Through-beam, 1 channel; light ON / dark ON set by control wire | 50 mm | Opaque material, min. Ø1.5 mm | |
| BMS300-DDT | Diffuse reflective | 300 mm | Opaque and translucent material |
Choosing the right one
Not sure this is the right sensors and encoder? Read the buying guide for sensors and encoders, then send us the details below so we can confirm a model.
- Sensor type: inductive, photoelectric, fibre, pressure or encoder
- Sensing distance, or pulses per revolution and shaft size for encoders
- Supply voltage and output type (NPN/PNP, NO/NC)
- Housing size or mounting details
- Existing part number if you are replacing a unit
