Sensing & instruments
Temperature controllers & instruments
Temperature and humidity controllers, power controllers, counters and panel meters.
Search and filter this categoryIn the catalogue
7 product lines listed
Buying guide
How to choose: temperature controllers and process instruments
Specifying a temperature controller
Confirm the sensor input first: thermocouple types J, K, T, R and S or an RTD such as Pt100. Then the control action (ON/OFF or PID with auto-tune), the output (relay, SSR drive or 4–20 mA), the panel size (for example 48 x 48 mm or 96 x 96 mm) and any alarm outputs. For heaters, pair the controller with a solid-state relay or thyristor power controller sized to the load current and mounted with adequate heat sinking.
Before you enquire
What to include in your enquiry
Having these details ready lets us confirm a model and quote in one step.
- Sensor type and temperature range
- Output required: relay, SSR drive or 4–20 mA
- Panel cut-out size
- Heater load in kW and supply voltage, for power controllers
